加工的中空玻璃尺寸 |
Min: 300x450mm, Max: 2500x3000mm, 2500x3500mm(over long unit, Optional) |
装配方式 | Outside automatic assembly, inside plate press |
电源 | 3-Phase, 4 wires, 380V 50Hz, 21.00 kW |
耗气量 | 800L/min |
清洗速度 | 2-8m/min |
最高工作速度 | 45m/min(adjustable according to requirement) |
单层玻璃厚度 | 3-15 mm |
中空玻璃厚度 | 12 ~ 50mm; |
空气供给 | 0.5-1.0Mpa, 0.8m3/min |
水电道侣 | ≦50μS/cm |
环境温度 | 10℃-30℃, following DIN 40040 |
空气相对湿度 | ≦75%,following DIN 40040 |
整体尺寸 | 33750x2300x3400mm |
